| General information |
|---|
| model: | honda st 1300 abs |
| Year: | 2005 |
| Category: | Sport touring |
| Engine and transmission |
|---|
| Displacement: | 1261.00 ccm (76.95 cubic inches) |
| Engine type: | V4 |
| Stroke: | 4 |
| Power: | 118.00 HP (86.1 kW) @ 8000 RPM |
| Torque: | 117.00 Nm (11.9 kgf-m or 86.3 ft.lbs) @ 6500 RPM |
| Compression: | 10.8:1 |
| Bore x stroke: | 78.0 x 66.0 mm (3.1 x 2.6 inches) |
| Fuel system: | Injection. Programmed Fuel Injection (PGM-FI) with automatic enricher circuit |
| Fuel control: | DOHC |
| Ignition: | Computer-controlled digital with three-dimensional mapping and electronic advance |
| Starter: | Electric |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
| Transmission type final drive: | Shaft drive (cardan) |
| Physical measures |
|---|
| Dry weight: | 288.9 kg (637.0 pounds) |
| Seat height: | 790 mm (31.1 inches) If adjustable, lowest setting. |
| Wheelbase: | 1,491 mm (58.7 inches) |
| Chassis and dimensions |
|---|
| Frame type: | Front Suspension |
| Rake (fork angle): | 26.0° |
| Trail: | 98 mm (3.9 inches) |
| Front suspension: | 45.0mm HMAS cartridge fork |
| Front suspension travel: | 117 mm (4.6 inches) |
| Rear suspension: | HMAS gas-charged single shock with five-position spring-preload adjustability; |
| Rear suspension travel: | 122 mm (4.8 inches) |
| Front tyre dimensions: | 120/70-ZR18 |
| Rear tyre dimensions: | 170/60-ZR17 |
| Front brakes: | Double disc. LBS 3-piston calipers. Anti-lock Braking System (ABS). |
| Front brakes diameter: | 310 mm (12.2 inches) |
| Rear brakes: | Single disc. LBS 3-piston calipers. Anti-lock Braking System (ABS). |
| Rear brakes diameter: | 316 mm (12.4 inches) |
| Speed and acceleration |
|---|
| Power/weight ratio: | 0.4084 HP/kg |
| Other specifications |
|---|
| Fuel capacity: | 29.14 litres (7.70 gallons) |
| Color options: | Candy Dark Red |
